Butterfly Valves Replaceable Seat
U-Section Wafer Butterfly Valve with Replaceable Seat, PN10/PN16
U-Section Butterfly Valve for Water treatment and industrial circulation systems. DN50–DN1200 | PN10 / PN16 | U-Section Wafer.
Quick Specifications
- Type
- U-Section Butterfly Valve
- Size
- DN50–DN1200
- Material
- Ductile Iron / CF8M Disc
- Pressure
- PN10 / PN16
- Connection
- U-Section Wafer
- Temperature
- -10 to 120°C
Product Details
The U-shaped body offers improved rigidity and flange alignment compared with a narrow wafer body. A field-replaceable molded liner, multiple disc coatings and ISO 5211 mounting enable economical maintenance and straightforward automation. This u-section butterfly valve is designed for water treatment and industrial circulation systems and can be supplied in DN50–DN1200 with U-Section Wafer connections. Body and trim materials, seat or sealing system, operator, coating and documentation can be customized to the actual medium, pressure, temperature and project specification. Manual, gearbox, pneumatic, hydraulic or electric operation is available where technically applicable. Dimensional inspection, shell and seat pressure testing, material certificates and application-specific inspection records can be provided with the order.
Specifications
| Parameter | Value |
|---|---|
| Model | GS-BFV-U16 |
| Design Standard | EN 593 |
| Size Range | DN50–DN1200 |
| Pressure Rating | PN10 / PN16 |
| Body Material | Ductile Iron / CF8M Disc |
| End Connection | U-Section Wafer |
| Temperature Range | -10 to 120°C |
| Typical Application | Water treatment and industrial circulation systems |
| Operation | Manual, gearbox or automated |
| Documentation | Pressure test and material reports available |
FAQ
How do you handle shipping and logistics?
We offer flexible shipping options including FOB, CIF, CFR, and DDP terms. Products are shipped via sea freight (most economical for bulk orders), air freight (for urgent/smaller orders), or courier (DHL/FedEx/UPS for samples). We handle all export documentation including commercial invoice, packing list, certificate of origin, and inspection certificates.
What is your minimum order quantity (MOQ)?
Minimum Order Quantity (MOQ) varies depending on product type and customization requirements. For standard products, the MOQ is typically 1 to 10 pieces. For OEM/ODM projects, the MOQ is typically 50 to 1000 pieces, depending on the complexity of the product. We welcome small sample orders for quality assessment.
What is the typical lead time for orders?
Standard products in stock: 7-15 days. Custom OEM orders: 30-60 days depending on specifications and quantity. We provide detailed production schedules and keep you updated throughout the manufacturing process. Rush orders can be accommodated for urgent requirements.
Need This Product for Your Project?
Send us your required size, material, pressure rating, quantity or applicable standard, and our team will review your requirement.
