PPH/PVDF Flanged Ball Valve, Manual, PN10/16
Manual PPH/PVDF flanged ball valve for removable corrosion-resistant process-line isolation.
Quick Specifications
Type
PPH/PVDF flanged ball valve
Size
DN15–DN200 (NPS 1/2–8)
Material
PPH or PVDF body/ball; PTFE seat; EPDM/FPM seals
Pressure
PN10 / PN16 (size and material dependent)
Connection
DIN / EN flanged ends
Temperature
PPH: up to 80 °C; PVDF: up to 120 °C (pressure derates with temperature)
Product Overview
A flanged plastic ball valve in PPH or PVDF for applications where threaded or socketed plastic connections are not suitable. PTFE seating and selectable elastomer seals support adaptation to corrosive chemical service.
Specifications
| Model | FL-PPH/PVDF-PN10/16 |
|---|---|
| Design Standard | ISO 16135 / DIN 3357; EN 1092-1 compatible flange drilling |
| Size Range | DN15–DN200 (NPS 1/2–8) |
| Pressure Rating | PN10 / PN16 (size and material dependent) |
| Body Material | PPH or PVDF body/ball; PTFE seat; EPDM/FPM seals |
| End Connection | DIN / EN flanged ends |
| Temperature Range | PPH: up to 80 °C; PVDF: up to 120 °C (pressure derates with temperature) |
| Typical Application | Chemical process piping, scrubber systems and corrosive-fluid transfer |
| Operation | Manual lever/gear; actuator option |
| Inspection & Documentation | Hydrostatic shell & seat test; dimensional drawing, material certificate and COC available on request |
